IC694MDL940

/ 4.9
1001 reviews | Need a Specific Revision?
In a PACSystems RX3i rack, General Electric IC694MDL940 provides sixteen normally open relay outputs for approved AC or DC field-load switching.
In Stock
Ships by Saturday, October 17
Fast Shipping Available
Get a quick price for IC694MDL940
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for IC694MDL940

  • Manufacturer:
    General Electric
  • Part Number:
    IC694MDL940
  • Product Family:
    GE PACSystems RX3i
  • Product Type:
    PACSystems RX3i Relay Output Module
  • Stock:
    1
  • Output Type:
    Normally open relay
  • Output Points:
    16
  • Output Rating:
    2 A
  • Documented Platform:
    PACSystems RX3i
  • Weight:
    0.34 kg
  • Estimated shipping dimensions:
    3.5 x 13.2 x 13.5 cm
  • Tariff Code:
    8537101190
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Specifications Relay Loads Terminal Plan Rack Change

Features:

  • Sixteen normally open relay output points
  • 2 A AC/DC switching designation
  • PACSystems RX3i rack I/O format
IC694MDL940 concentrates sixteen relay-operated normally open circuits in one PACSystems RX3i rack position.

Because contacts are electromechanical, load inrush, contact protection, switching frequency, and maintenance expectations shape the engineering decision more than semiconductor logic direction.

Acceptance should connect the exact module label to its terminal block, slot assignment, field-load schedule, protective devices, point-by-point functional test, and final project backup.

Availability is subject to Apter Power's current inventory and sourcing confirmation.
IC694MDL940 Manuals, Datasheets, Links Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
IC694MDL940 PACSystems RX3i Relay Output Module Specs

General

  • ManufacturerGeneral Electric
  • ModelIC694MDL940
  • ConditionNew Original ready stock
  • Product FamilyGE PACSystems RX3i
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

Field-load review for relay contacts

  • Load class: Identify each circuit as resistive, inductive, lamp, or another documented field load.
  • Inrush: Compare pickup or starting current with the permitted relay contact duty.
  • Suppression: Apply the approved protection method to coils and other inductive devices.
  • Cycle rate: Include switching frequency and expected contact wear in the maintenance plan.

Removable terminal-block preparation

  • Accessory: Confirm whether the required removable terminal block is included with the stock item.
  • Wire record: Preserve terminal numbers, commons, conductor labels, and destination devices.
  • Inspection: Check latches, pins, screws, and strain relief before conductor transfer.
  • Proof test: Prove every relay command and field response after reinstallation.

Controlled RX3i module replacement

  • Identity: Match the complete catalog number before disturbing the installed module.
  • Isolation: Use the approved electrical and process isolation procedure.
  • Configuration: Retain the rack slot and project hardware assignment.
  • Handover: Archive the load schedule, wiring check, test results, and updated drawings.
Description
Within the PACSystems RX3i rack-based I/O platform, IC694MDL940 is a sixteen-point normally open relay output module with a 2 A designation. Its electromechanical contacts distinguish the module from positive- or negative-logic semiconductor outputs used elsewhere in the I/O catalog.

Mixed field-load planning is the practical focus for IC694MDL940: the relay architecture can switch approved AC or DC circuits, while operating voltage, steady current, pickup or lamp inrush, switching frequency, suppression, and required safe state must be resolved for each connected device.

A procurement record for IC694MDL940 should retain the complete catalog number, RX3i rack position, removable terminal-block requirement, conductor map, protection method, and load schedule. The official RX3i I/O data sheet also identifies a six-pack of twenty-terminal blocks for the relevant rack I/O modules.
Revisions

Revision Part #

Also known as

IC694MDL940 Rev A
IC694MDL940A, Revision A, Initial release
IC694MDL940 Rev D
IC694MDL940D, Revision D, Hardware update
IC694MDL940 Rev E
IC694MDL940E, Revision E, RoHS version
IC694MDL940 Rev F
IC694MDL940F, Revision F, Emerson-branded version
Alternative Names
IC694 MDL 940 IC 694 MDL 940 PACSystems RX3i 16-point relay output module RX3i normally open relay output card GE 2 A relay output module PACSystems rack relay output module
Technical notes
Treat IC694MDL940 as an electromechanical switching module, not a semiconductor output. Before deployment, resolve each field circuit’s AC or DC voltage, steady current, inrush, switching frequency, suppression, safe state, and removable terminal-block scope; the RX3i I/O data sheet documents the applicable rack I/O terminal hardware.
